利用Python如何实现K-means聚类算法

import numpy as np
import matplotlib.pyplot as plt
import random
from sklearn.datasets import make_blobs
np.random.seed(123)
from sklearn.cluster import KMeans
class Kmeans:
    def __init__(self,data,k):
        self.data=data
        self.k = k
    def cluster_data_Bysklearn(self):
        kmeans_model = KMeans(self.k,random_state=1)
        labels = kmeans_model.fit(self.data).labels_
        print(labels)
        return labels

    def kmeans(self):
        # 获取4个随机数
        rarray = np.random.random(size=self.k)
        # 乘以数据集大小——>数据集中随机的4个点
        rarray = np.floor(rarray * len(self.data))
        # 转为int
        rarray = rarray.astype(int)
        print('数据集中随机索引', rarray)
        # 随机取数据集中的4个点作为初始中心点
        center = data[rarray]
        # 测试比较偏、比较集中的点，效果依然完美，测试需要删除以上代码
        # center = np.array([[4.6,-2.5],[4.4,-1.7],[4.3,-0.7],[4.8,-1.1]])
        # 1行80列的0数组，标记每个样本所属的类(k[i])
        cls = np.zeros([len(self.data)], np.int)
        print('初始center=\n', center)
        run = True
        time = 0
        n = len(self.data)
        while run:
            time = time + 1
            for i in range(n):
                # 求差
                tmp = data[i] - center
                # 求平方
                tmp = np.square(tmp)
                # axis=1表示按行求和
                tmp = np.sum(tmp, axis=1)
                # 取最小（最近）的给该点“染色”（标记每个样本所属的类(k[i])）
                cls[i] = np.argmin(tmp)
            # 如果没有修改各分类中心点，就结束循环
            run = False
            # 计算更新每个类的中心点
            for i in range(self.k):
                # 找到属于该类的所有样本
                club = data[cls == i]
                # axis=0表示按列求平均值，计算出新的中心点
                newcenter = np.mean(club, axis=0)
                # 如果新旧center的差距很小，看做他们相等，否则更新之。run置true，再来一次循环
                ss = np.abs(center[i] - newcenter)
                if np.sum(ss, axis=0) > 1e-4:
                    center[i] = newcenter
                    run = True
            print('new center=\n', center)
        print('程序结束，迭代次数：', time)
        # 按类打印图表，因为每打印一次，颜色都不一样，所以可区分出来
        # for i in range(self.k):
        #     club = data[cls == i]
        #     self.showtable(club)
        # 打印最后的中心点
        self.showtable(center)
        #打印聚类标签
        print(cls)

    def showtable(self,data):
        x = data.T[0]
        y = data.T[1]
        plt.scatter(x, y)
        plt.show()

if __name__ == '__main__':
    data = np.random.rand(10,2)
    K = 4
    model = Kmeans(data,K)

    model.kmeans()
    model.cluster_data_Bysklearn()

import numpy as np
import matplotlib.pyplot as plt
import random
from sklearn.datasets import make_blobs


%matplotlib inline

X, y = make_blobs(centers=6, n_samples=1000)
print(f'Shape of dataset: {X.shape}')

fig = plt.figure(figsize=(8,6))
plt.scatter(X[:,0], X[:,1], c=y)
plt.title("Dataset with 6 clusters")
plt.xlabel("First feature")
plt.ylabel("Second feature")
plt.show()

class KMeans():
    def __init__(self, n_clusters=6):
        self.k = n_clusters

    def fit(self, data):
        """
        Fits the k-means model to the given dataset
        """
        n_samples, _ = data.shape
        # initialize cluster centers
        self.centers = np.array(random.sample(list(data), self.k))
        self.initial_centers = np.copy(self.centers)

        # We will keep track of whether the assignment of data points
        # to the clusters has changed. If it stops changing, we are
        # done fitting the model
        old_assigns = None
        n_iters = 0

        while True:
            new_assigns = [self.classify(datapoint) for datapoint in data]

            if new_assigns == old_assigns:
                print(f"Training finished after {n_iters} iterations!")
                return

            old_assigns = new_assigns
            n_iters += 1

            # recalculate centers
            for id_ in range(self.k):
                points_idx = np.where(np.array(new_assigns) == id_)
                datapoints = data[points_idx]
                self.centers[id_] = datapoints.mean(axis=0)

    def l2_distance(self, datapoint):
        dists = np.sqrt(np.sum((self.centers - datapoint)**2, axis=1))
        return dists

    def classify(self, datapoint):
        """
        Given a datapoint, compute the cluster closest to the
        datapoint. Return the cluster ID of that cluster.
        """
        dists = self.l2_distance(datapoint)
        return np.argmin(dists)

    def plot_clusters(self, data):
        plt.figure(figsize=(12,10))
        plt.title("Initial centers in black, final centers in red")
        plt.scatter(data[:, 0], data[:, 1], marker='.', c='y')
        plt.scatter(self.centers[:, 0], self.centers[:,1], c='r')
        plt.scatter(self.initial_centers[:, 0], self.initial_centers[:,1], c='k')
        plt.show()

X = np.random.randn(10,100)
kmeans = KMeans(n_clusters=6)
kmeans.fit(X)
for data in X:
    print(kmeans.classify(data))
